24" Battery Trowel

CPT-20BR

610mmWorking Diameter

2kW DC motor, Lithium-Ion battery
Set screw adjustment system
Easy to transport
Work to edge

The CIMAR CPT-20BH Battery Trowel is a compact and versatile tool designed to deliver exceptional performance in a wide range of working conditions. With its small working radius and manual screw unit, this power trowel is suitable for various applications.

Send A Inquiry

Description

The set screw control unit allows for precise blade adjustment, ensuring accurate and efficient operation
The safe handle design ensures that the machine remains on when any one of the handles is held, providing enhanced safety for the operator
The folded handle design allows for convenient transportation and space-saving storage
The throttle lever on the handle provides convenient and easy control
The engineering plastic belt cover effectively prevents sand, soil, and dust from entering, resulting in a longer lifespan for both the engine and clutch
The CIMAR aluminum reducer is highly reliable, ensuring a longer lifespan for the power trowel
The 1.5mm thick T8A blade can cover an impressive 6000 square meters of working area. With a combination blade and finish blade, it can handle various types of working tasks
An optional 24" turbo disc is available for additional versatility and performance

Specifications

Engine Type		CQTS2000
Max. Power Output	kW(PS)	2(2.7)
Trowel Speed	r.p.m	0-100
Weight	Kg	58
Dimensions	L (mm)	1000
	W (mm)	600
	H (mm)	600
Trowel Dia	mm	610
Blade Size	L (mm)	255
	W (mm)	125
	T (mm)	1.5
Battery Voltage	Volt	72
Battery Capacity	Ah	15/20
Runtime per Cycle	min	60
Charging Time	min	60
Cycles	time	500+
Run Temperature	℃	-5~60
Charging Temperature	℃	0~45
