350kg Reversible Plate Compactor


45kNImpact Force
800x485mmPlate Size



  • High Performance
  • Heavy Duty
  • Hydraulic Direction System
  • Casting Ductile Iron Plate And Base



The CPC-350 is a large-sized reversible plate compactor designed for efficient compaction in large areas and patching conditions. It can be installed with both petrol and diesel engines for added versatility. An optional extension plate is also available to enlarge the base and enhance efficiency.

Send A Inquiry


  • The hydraulic direction mechanism allows the machine to move forward, backward, and on-spot-compaction.
  • The casting aluminum throttle lever is durable and comfortable for the operator to use.
  • The closed-style frame protects the engine, and the hook makes it easy to transport.
  • The casting aluminum belt cover cools easily, prolonging the lifespan of the engine and clutch while also preventing sand, soil, and dust from entering.
  • A high-quality shock absorber reduces vibration, making the operator more comfortable.
  • The ductile iron base is durable and strong.
  • Only for diesel engines, the electric switch makes it more efficient for the operator to start the machine.
  • The sealed battery design protects the battery, only for diesel engines.
  • The optional extension plate (12kg) enlarges the base and enhances efficiency.
  • The plate compactor with a optional rubber mat is suitable for bricks.


Engine Type Yanmar L100
Max. Power Output kW(ps) 6.5(10.0)
Weight Kg 350
Dimension L (mm) 1570
W (mm) 485
H (mm) 930
Plate Size L (mm) 860
W (mm) 485
Vibration Frequency Hz(vpm) 73(4400)
Centrifugal Force kN(kgf) 45
Max.Traveling Speed(Depending on materials) m/min 23
Limited Gradient % 30%


  • Hydraulic System

  • Aluminum Throttle Lever

  • Closed Frame

  • Electric Switch
